DC City Charger
Publicly accessible infrastructure needs to be durable, reliable and fit for purpose. The Delta DC City Charger is designed to deliver.
This charger will deliver longevity and robustness. Available in three output variants (50kW, 100kW and 200kW), the City Charger will deliver rapid and ultra-rapid performance.
50kW / 100kW / 200 kW max. output
Charger up to two vehicle silmultaneously
Fitur dual CCS2 plug types
Smart connectivity via Ethernet, Wi-Fi or SIM card
Accessible via RFID or third party charge point operators*
IP55 protection and IK10 vandal-proof casing
Specification
| DC City Charger 50kW | DC City Charger 100kW | DC City Charger 200kW | |
|---|---|---|---|
| Input / output rating | 380-415 Vac, 3-phase, L1, L2, L3, N, PE, 50/60Hz |
380-415 Vac, 3-phase, L1, L2, L3, N, PE, 50/60Hz |
380-415 Vac, 3-phase, L1, L2, L3, N, PE, 50/60Hz |
| Output power (max.) | 50kW + 22kW | 100kW + 22kW | 200kW |
| Plug type | CCS2 | CCS2 | CCS2 |
| Ingress & impact protection | IP55 / IK10 | IP55 / IK10 | IP55 / IK10 |
| Cable length | 4 m & 7.5 m (optional) | 4 m & 7.5 m (optional) | 4 m & 7.5 m (optional) |
| Dimension (WxHxD) | 800 x 1500 x 590 mm | 800 x 1500 x 590 mm | 850 x 1800 x 680 mm |
| Weight | 290 kg (excl. charging connectors) | 350 kg (excl. charging connectors) | 420 kg (excl. charging connectors) |
| Installations | Ground mount | Ground mount | Ground mount |
| Security | ISO/IEC14443A/RFID | ISO/IEC14443A/RFID | ISO/IEC14443A/RFID |
| Communication | Ethernet, Wi-Fi, 4G SIM | Ethernet, Wi-Fi, 4G SIM | Ethernet, Wi-Fi, 4G SIM, RFID |
| Communication protocol | OCPP 1.6J, OCPP1.6J-Secured, upgradable to OCPP 2.0 |
OCPP 1.6J, OCPP1.6J-Secured, upgradable to OCPP 2.0 |
OCPP 1.6J, OCPP1.6J-Secured, upgradable to OCPP 2.0 |
DC City Charger 50kW
Input / output rating380-415 Vac, 3-phase, L1, L2, L3, N, PE, 50/60Hz
Output power (max.)50kW + 22kW
Plug typeCCS2
Ingress & impact protectionIP55 / IK10
Cable length4 m & 7.5 m (optional)
Dimension (WxHxD)800 x 1500 x 590 mm
Weight290 kg (excl. charging connectors)
InstallationsGround mount
SecurityISO/IEC14443A/RFID
CommunicationEthernet, Wi-Fi, 4G SIM
Communication protocolOCPP 1.6J, OCPP1.6J-Secured, upgradable to OCPP 2.0
DC City Charger 100kW
Input / output rating380-415 Vac, 3-phase, L1, L2, L3, N, PE, 50/60Hz
Output power (max.)100kW + 22kW
Plug typeCCS2
Ingress & impact protectionIP55 / IK10
Cable length4 m & 7.5 m (optional)
Dimension (WxHxD)800 x 1500 x 590 mm
Weight350 kg (excl. charging connectors)
InstallationsGround mount
SecurityISO/IEC14443A/RFID
CommunicationEthernet, Wi-Fi, 4G SIM
Communication protocolOCPP 1.6J, OCPP1.6J-Secured, upgradable to OCPP 2.0
DC City Charger 200kW
Input / output rating380-415 Vac, 3-phase, L1, L2, L3, N, PE, 50/60Hz
Output power (max.)200kW
Plug typeCCS2
Ingress & impact protectionIP55 / IK10
Cable length4 m & 7.5 m (optional)
Dimension (WxHxD)850 x 1800 x 680 mm
Weight420 kg (excl. charging connectors)
InstallationsGround mount
SecurityISO/IEC14443A/RFID
CommunicationEthernet, Wi-Fi, 4G SIM, RFID
Communication protocolOCPP 1.6J, OCPP1.6J-Secured, upgradable to OCPP 2.0
